ZTX957STZ Diodes TRANS PNP 300V 1A E-LINE
ZTX957STZ Images
ZTX957STZ Images
  • Manufacturer: Diodes Inc. (Diodes)
  • Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: E-Line-3, Formed Leads
  • Description: TRANS PNP 300V 1A E-LINE
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
ZTX957STZ Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
ZTX957STZ Specifications:
  • MfrPart.: ZTX957STZ
  • Mfr: Diodes Incorporated
  • Description: TRANS PNP 300V 1A E-LINE
  • Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
  • Package: Tape & Box (TB)
  • Series: -
  • PartStatus: Active
  • TransistorType: PNP
  • Current-Collector(Ic)(Max): 1 A
  • Voltage-CollectorEmitterBreakdown(Max): 300 V
  • VceSaturation(Max)@IbIc: 200mV @ 300mA, 1A
  • Current-CollectorCutoff(Max): 50nA (ICBO)
  • DCCurrentGain(hFE)(Min)@IcVce: 100 @ 500mA, 10V
  • Power-Max: 1.2 W
  • Frequency-Transition: 85MHz
  • OperatingTemperature: -55°C ~ 200°C (TJ)
  • MountingType: Through Hole
  • Package/Case: E-Line-3, Formed Leads
  • ZTX957STZ Diodes Inc. (Diodes), TRANS PNP 300V 1A E-LINE, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
ZTX957STZ, Diodes authentic parts in stock from Diodes Inc. (Diodes) authorized distributors, order today, can ship immediately.
