ZTX755 Diodes TRANS PNP 150V 1A E-LINE
ZTX755 Images
ZTX755 Images
  • Manufacturer: Diodes Inc. (Diodes)
  • Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: E-Line-3
  • Description: TRANS PNP 150V 1A E-LINE
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
ZTX755 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
ZTX755 Specifications:
  • MfrPart.: ZTX755
  • Mfr: Diodes Incorporated
  • Description: TRANS PNP 150V 1A E-LINE
  • Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
  • Package: Bulk
  • Series: -
  • PartStatus: Obsolete
  • TransistorType: PNP
  • Current-Collector(Ic)(Max): 1 A
  • Voltage-CollectorEmitterBreakdown(Max): 150 V
  • VceSaturation(Max)@IbIc: 500mV @ 200mA, 1A
  • Current-CollectorCutoff(Max): 100nA (ICBO)
  • DCCurrentGain(hFE)(Min)@IcVce: 50 @ 500mA, 5V
  • Power-Max: 1 W
  • Frequency-Transition: 30MHz
  • OperatingTemperature: -55°C ~ 200°C (TJ)
  • MountingType: Through Hole
  • Package/Case: E-Line-3
  • ZTX755 Diodes Inc. (Diodes), TRANS PNP 150V 1A E-LINE, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
ZTX755, Diodes authentic parts in stock from Diodes Inc. (Diodes) authorized distributors, order today, can ship immediately.
