Diodes Incorporated's experienced design team has created popular functions in four major logic families. Very low power AUP products are available to save milliwatts and extend battery life. The LVC family is an industry-standard that has the drive and speed to work well in many demanding applications. HC and AHC legacy parts have been re-engineered on advanced wafer processes allowing for a continuous product supply well into the future.

Diodes Incorporated provides an assortment of small package options, allowing manufacturers to choose a size and lead pitch that will be compatible with their standard manufacturing processes. Most of the logic products are assembled in Diodes Incorporated's proprietary factories, which enables direct control of quality and cost along with the dedicated capacity to meet customer needs. While logic is often considered a commodity device, the newest miniature package offerings from Diodes Incorporated are enabling the advancement of the next generation of tiny portable consumer products.

Dual Gate

Diodes Incorporated provides excellent Single and Dual Gate Logic Devices, designed to use DFN packaging options to better suit today’s sophisticated products which require more functions and features packed into a much smaller space.

The industry standard LVC family has the drive and speed to work well with many demanding applications. The AUP family is also incredibly reliable. Contained in several available options of the AUP family is the DFN0910 package, which at 0.9mm x 1.0mm is the smallest available foot print.

Single Gate

Diodes Incorporated provides excellent Single and Dual Gate Logic Devices, designed to use DFN packaging options to better suit today’s sophisticated products which require more functions and features packed into a much smaller space.

Standard Logic

Diodes Incorporated's Standard Logic devices offer a wide supply voltage range and are supported by an array of packages including QFN for small space-constrained systems.

Voltage Translators

Diodes Incorporated offers a variety of voltage level translation ICs that provide mixed signal (I C, SMBus, MDIO, SPI, SIM I/F, TTL, HSTL and SSTL) as well as multiple supply voltages (5V, 3.3V, 2.5V, 1.8V, 1.2V and 0.9V).

Analog Switches

Diodes Incorporated’s logic products are offered in a wide variety of packages to meet the design needs of both cutting-edge and legacy products.

Interface Logic

Diodes offers high-speed voltage translators, performance logic and other specialty Interface IC solutions for memory modules. These products offer high performance 5 V, 3.3 V, 2.5 V and 1.8 V with propagation delays down to < 2.0ns. They support 8-bit, 16-bit, 18-bit and 32-bit functions with a performance mix of voltage translators.

Diodes' multiplexers and switches offer solutions for a variety of applications with 2, 4, and 8-channel devices. IO expander products are available with I2C bus interface and 2 to 48 IOs. Diodes' GTL devices are used in point to point applications. Diodes' portfolio of Standard Logic devices offer wide supply voltage range and are supported by an array of packages including QFN for small space-constrained systems.
