Diodes Incorporated provides product designers with a broad range of discrete semiconductor components that are renowned for their quality, high performance and optimized packaging.



A focus on product innovation driven by customer requirements has resulted in ultra, high-performing MOSFETs.

Diodes' wide range of Insulated Gate Bipolar Transistors (IGBTs) provides a combination of MOSFET gate driver characteristics with the high and low current saturation voltage capability of bipolar transistors.

Consisting of a wide array of Diode types, from Zener and Schottky (Less than .5A), to Small Signal Switching and PFC Diodes (DIODESTAR) our diverse Diodes portfolio guarantees there is one for every application need . Diodes' Rectifier selection is equally as diverse, with Schottky (.5A and Above), Standard Rectifiers as well as Fast/Ultra-Fast Rectifiers, Bridges, Performance (SBR) and High-performance Trench Super Barrier Rectifiers (SBRT).

Diodes have designed protection devices to enable hassle-free ESD protection for an abundance of machinery.

Diodes' functional arrays utilize our in-house packaging expertise and provide simple solutions which result in their ability to function in many different markets.



Diodes is the market leader when it comes to Bipolar transistors. By utilizing its wide line up of in-house packaging and superior silicon technology, Diodes is ideally positioned to meet your application needs for Bipolar transistors.



Continued Innovation

The Bipolar transistor portfolio is built on successive generations of our innovative matrix emitter process. Years of know-how, leading edge designs and process innovation have extended our leadership in building ultra-low saturation, fast switching transistors.



Best-in-Class Performance

With focus on optimizing processes for the lowest saturation voltage, reduced die area and subsequently improved switching performance, the consequent reduction in power dissipation allows ever smaller surface mount packages, which still meet the demands of the target applications. The inherent ruggedness to ESD of the Bipolars along with their very low specific on-resistance also make them very cost-effective alternatives to MOSFET technology in a wide range of circuit topologies.



Application-Specific Products

Market demands for improved electronic systems solutions, whether in terms of improved efficiency, increased power density, or just cost reduction, drive all our application specific products.



Avalanche transistors, Gate drivers and H-bridge devices have all been developed to create dedicated solutions driven by customer needs and combine the benefits of the exceptional transistor die performance with Diodes packaging expertise.



Quality

The majority of the products in the Diodes' Bipolar transistor portfolio are designed to meet the stringent requirements of the Automotive Electronic Council specification AECQ101.



Functional Arrays



Diodes Incorporated's functional arrays are multi-die, simple, application-specific standard products providing solutions in many different markets.



These include:



Simple single and multi-channel relay drivers using Diodes in-house packaging expertise.

Simple high-voltage regulators combining zeners or references with Diodes' bipolar transistors.

Simple LED driver solutions offering built-in LED current reduction at high temperatures.

Simple transistor + Diodes' arrays offering versatile solutions with large footprint savings compared with traditional discrete solutions.



IGBTs



Diodes' range of Insulated Gate Bipolar Transistors (IGBTs) use advanced Field Stop Trench IGBT Technology to offer rugged performance combined with super high-speed switching performance in industry standard packages.



IGBTs combine the gate drive characteristics of MOSFETs with the high current and low saturation voltage capability of bipolar transistors. IGBTs are used in medium to high-power applications such as Uninterruptable Power Supplies (UPS), motor drive, welders, solar inverters and induction cookers.



MOSFETs - Ultra High-performing

The breadth of the Diodes Incorporated MOSFET portfolio enables designers to select a device optimized for their end application, thus enabling next generation consumer, computer and communication product designs.



The Diodes portfolio is ideally suited to meeting the circuit requirements of:



DC-DC conversion

load switching

motor control

backlighting

battery protection

battery chargers

audio circuits

automotive applications



The majority of products in the Diodes MOSFET product portfolio are designed to meet the stringent requirements of AEC-Q101 reliability standard of the Automotive Electronic Council. Products with a 'Q' suffix indicate that the product is Automotive grade – the device has passed the rigorous AEC-Q101 standard and is fully supported for Automotive customers with PPAP (Production Part Approval Process), and IATF16949 approved manufacturing sites.



Furthermore, all in-house packaging utilizes environmentally 'green' mold compound.



Protection Devices



Diodes Incorporated's protection devices provide leading-edge performance and rugged quality to aid the customer in a successful first-time, right-system design. Diodes' top prorities are our customers' needs and short lead times to facilitate those needs.



Diodes' Zener TVS portfolio spans from low-voltage 3.3V up to 440V, while achieving high surge protection ratings: up to 3.0kW or 326A equivalent.



Diodes' Thyristor Surge Protection Devices (TSPD) provide lightning surge suppression for intra-building protection according to Bellcore GR-1089 and system-level protection according to IEC 61000-4-5.



Diodes' Data Protection Devices are a rapidly expanding portfolio, targeting best-in-class ESD performance with a wide range of selectable package options to address customer-specific needs.



Diodes' protection devices are offered in the smallest industry-standard DFN package 0201 (0603 metric) and provide best-in-class system-level ESD performance by exceeding 30kV IEC 61000-4-2 contact and air discharge.



Diodes protection devices are specifically designed to assist in worry-free, system-level ESD protection for:



Set-top boxes (STB)

Data communication (cable modems, wireless routers)

Mobile communication (smart phones, tablet PCs, PDAs, e-book readers)

High-speed data lines (USB 2.0, USB 3.0, HDMI , DisplayPort, Thunderbolt™)

PC and game consoles

Infotainment devices

Automotive applications

Audio and antenna protection



Thunderbolt is a trademark of Intel Corporation.

Do you know more about Diodes's product uses, technical documents, and solutions related to Discrete Semiconductor Components? Then quickly get in touch with Diodes Inc. (Diodes) Distributor - NANHUANG!
