Diodes Incorporated’s Frequency Controlled Products (FCP) consists of both quartz crystal resonators and crystal oscillators. Leveraging our own in-house crystal and IC design, Diodes Incorporated provides the best-in-class crystal (Xtal) and crystal oscillators (XO) optimized for your design requirements.

Diodes Incorporated has a wide portfolio of level shifter and level translator devices that can solve today’s communication issues among mixed applications, as many products are bidirectional and scalable from 1-bit to +32-bits with support for power from 1.5V to 5V.

voltage translator, level shifter, voltage level shift

Diodes offers a variety of voltage level shifters and voltage level translators that provide mixed signal logic functionality as well as multiple supply voltages. Diodes’ high-speed voltage translator, voltage shifter, and other specialty Interface IC solutions for memory modules offer high performance with low propagation delays. They support 8-bit, 16-bit and 32-bit functions with a performance mix of voltage translators. Diodes' variety of universal level shifter (ULS) ICs and voltage translator ICs provide TTL, HSTL and SSTL functions, as well as supply voltages from 1.2V to 5V.

Diodes' serial bridge portfolio ranges from cost-effective I2C/SPI Universal Asynchronous Receiver/Transmitters (UARTs), to high-performance multi-port PCI express (PCIe) UARTs.

The Low Voltage Differential Signaling (LVDS) product line offers line drivers, receivers, transceivers, crosspoints, clock/data distribution and repeaters that solve today's high speed I/O interface translation requirements supporting 8-bit, 16-bit, 18-bit and 32-bit functions.

Diodes' multiplexers and switches offer solutions for a variety of applications with 2, 4, and 8-channel devices. IO expander products are available with I2C bus interface and 2 to 48 IOs. Diodes' GTL devices are used in point to point applications. Diodes' portfolio of Standard Logic devices offer wide supply voltage range and are supported by an array of packages including QFN for small space-constrained systems.

Diodes' line of HDMI and DisplayPort Repeaters equalize input signals and reduce jitter on the display data signal path. Increased signal jitter margin provides engineers the system design flexibility, BOM cost reduction, and improves their time-to-market. Diodes' display switches are compact, highly integrated, cost-competitive, power efficient, and have low jitter and high electrostatic discharge (ESD) protection.

The ReDriver, also known as repeater IC, regenerates signals to boost the signal quality of high-speed interfaces.  Faster signal frequencies leave designers with less signal margin with which to design reliable, high-performance systems.  Using equalization, pre-emphasis, and other technologies, a single Redriver can adjust and correct for known channel losses at the transmitter and restore signal integrity at the receiver.  This results in an eye pattern at the receiver with the margins required to deliver reliable communications with low bit error rates (BER).

High-speed signal routing is Diodes' focus within the Silicon Switch™ product family such as Signal Switch IC and Multiplexers. Diodes' patented Charge Pump technology provides the highest signal integrity and achieves the most efficient and clear signal routing for data rates up to 12 Gbps.

Diodes is a member of PCI-SIG®, HDMI™, USB.org, and VESA®. Diodes' PCI-Express® 1.0, 2.0 and 3.0, HDMI, DVI, DisplayPort™, LVDS, USB 2.0 with SuperSpeed 3.0, and SATA2.0, SATA3.0, SAS1.0, SAS2.0, 10GE, Thunderbolt™ signal switches have all been designed with the application clearly in mind. Customers that design for digital television, set-top box, notebook PC and desktop PC applications benefit from our breadth of knowledge and design technology in routing high-speed signals across PCB or cables.

See our Type-C connector solution.

There are 3 categories of signal switches/multiplexers. They are Analog Switch, Digital Bus Switch and Protocol Switch
