DMP2123LQ-13 Images
- Manufacturer: Diodes Inc. (Diodes)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-23
- Description: MOSFET P-CH 20V 3A SOT23
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
DMP2123LQ-13 Specifications:
- MfrPart.: DMP2123LQ-13
- Mfr: Diodes Incorporated
- Description: MOSFET P-CH 20V 3A SOT23
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 3A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 2.5V, 4.5V
- RdsOn(Max)@IdVgs: 72mOhm @ 3.5A, 4.5V
- Vgs(th)(Max)@Id: 1.25V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 7.3 nC @ 4.5 V
- Vgs(Max): ±12V
- InputCapacitance(Ciss)(Max)@Vds: 443 pF @ 16 V
- FETFeature: -
- PowerDissipation(Max): 1.4W (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SOT-23
- DMP2123LQ-13 Diodes Inc. (Diodes), MOSFET P-CH 20V 3A SOT23, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
