DMN2055U-13 Images
- Manufacturer: Diodes Inc. (Diodes)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-23
- Description: MOSFET N-CH 20V 4.8A SOT23 T&R 1
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
DMN2055U-13 Specifications:
- MfrPart.: DMN2055U-13
- Mfr: Diodes Incorporated
- Description: MOSFET N-CH 20V 4.8A SOT23 T&R 1
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 4.8A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 2.5V, 4.5V
- RdsOn(Max)@IdVgs: 38mOhm @ 3.6A, 4.5V
- Vgs(th)(Max)@Id: 1V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 4.3 nC @ 4.5 V
- Vgs(Max): ±8V
- InputCapacitance(Ciss)(Max)@Vds: 400 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 800mW (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SOT-23
- DMN2055U-13 Diodes Inc. (Diodes), MOSFET N-CH 20V 4.8A SOT23 T&R 1, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
